W6300-Q
€2.26
€1.90
Delivery Time: 7 days for quantities in stock. Backordered pieces: 4 weeks
high-speed IPv4/IPv6 hardwired TCP/IP with 64 kB memory
Product Description
The W6300 is a WIZnet 10/100 MBit/s TOE (TCP Offload Engine) Ethernet chip that combines the high-speed ethernet performance with Dual IPv4/IPv6 Hardware stack. To support the Ethernet performance up to 80 Mbps, it supports a 150 MHz system clock and a QSPI interface (including 4 Data lines). The W6300 supports a total SRAM size of 64 kB for 8 sockets, where each has 4 kB TX/RX buffer by default.
Features
- Supports hardwired TCP/IP protocols: TCP, UDP, IPv6, IPv4, ICMPv6, ICMPv4, IGMP, MLDv1, ARP, PPPoE
- Supports IPv4/IPv6 dual stack
- Supports 8 independent SOCKETs simultaneously with 64 kB memory
- Supports SOCKET-less commands: ARP, ICMPv6 (ARP, DAD, NA, RS) command for IPv6 auto-configuration & network monitoring (PING, PING6)
- Supports Ethernet PHY power down mode & system clock switching for power save
- Supports Wake on LAN over UDP
- Support Serial & Parallel Host Interface: High Speed QSPI(MODE 0/3), System Bus with 2 Address signal & 8bit Data
- Internal 32 kB memory each for TX/RX Buffers (total of 64 kB memory)
- 10BaseT/10BaseTe/100BaseTX Ethernet PHY integrated
- Supports auto negotiation (full/half duplex, 10 and 100-based)
- Supports auto-MDIX only on auto-negotiation mode
- Does not support IP fragmentation & jumbo packet
- 3V operation with 5V I/O signal tolerance
- Network indicator LEDs (full/half duplex, link, 10/100 speed, active)
- 48 Pin QFN lead-free package (7x7mm, 0.5mm pitch)
Related Links
| Manufacturer / Hersteller | WIZnet Korea |
|---|---|
| Dimension | 7 mm x 7 mm, 0.5 mm pitch |
| Ethernet I/F | PHY |
| Operating Temperature | -40 °C to +85 °C |
| Operating Voltage | 3.3 V |
| Functions | 3-in-1, TCP/IP + MAC + PHY |
| Network sockets count | 8 |
| internal DPRAM buffer memory | 64 kB |
| Package | QFN |
| pin count chip | 48 |
| MCU I/F | SPI |
| pin pitch | 0.50 mm |
| Ethernet Speed | 10/100 |
| Protocol | IPv4, IPv6 |
| Auto Negotiation | Yes |
| Wake on Lan | Yes |
| Power Down Mode | Yes |
| MCU core | ARM Cortex M0 |
| Core speed | 96 MHz |
