WIZ750SR-485-EVB
€45.22
€38.00
Delivery Time: 7 days for quantities in stock. Backordered pieces: 4 weeks
Evaluation Board for the Serial-to-Ethernet module WIZ750SR-485
Product Description
WIZ750SR-EVB is a evaluation board for WIZ750SR.
WIZ750SR is the compact sized serial to Ethernet module using W7500P, WIZnet iMCU based on Cortex-M0 MCU core. WIZ750SR is the protocol converter that transmits the data sent by serial equipment as TCP/IP data type, and converts back the TCP/IP data received through the network into serial data to transmit back to the equipment
It supports the serial interface of RS422/485.
WIZ750SR-TTL/RS232 Module
- TCP/IP : W7500P
- PHY : Embedded in W7500P
- RJ-45 : BS-RB10005 (Transformer Integrated)
- MCU : Cortex-M0 (W7500) : SRAM : 48K Byte, FLASH-128Kbyte, 6Kbyte
- Boot ROM and 32KByte Socket SRAM
- Serial : RS-422/485 (SP3485EN, transceiver chip mounted)
- Pinout interface
6×2 2.54mm Pin Header (Male) 1EA
1×6 2.54mm Pin Header (Male) 2EA
1×2 2.54mm Pin Header (Male) 1EA
Base Board
- Module Interface
- 6×2 2.54mm Pin Header (FeMale) 1EA
- 1×6 2.54mm Pin Header (FeMale) 2EA* 1×2 2.54mm Pin Header (FeMale) 1EA
- Serial Connector : D-SUB, 9PIN, Right Angle, Male
- Serial Connector : BR-508LH-6Pin (6pin Terminal Block)
- Power : DC Jack mounted (External : 4.5Ø, Internal :1.3Ø)
Related Links
| Manufacturer / Hersteller | WIZnet Korea |
|---|---|
| Dimension | 45 mm x 30 mm |
| Ethernet I/F | PHY |
| Operating Temperature | 0 °C to +70 °C |
| Auto Negotiation | Yes |
| Network sockets count | 8 |
| internal DPRAM buffer memory | 32 kB |
| Wake on Lan | No |
| Power Down Mode | No |
| Protocol | IPv4 |
| MCU core | ARM Cortex M0 |
| ROM | 128 kB |
| RAM | 48 kB |
| voltage regulator (LDO) | Yes |
| Ethernet Speed | 10/100 |
