WIZ550S2E-TTL

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

  • WIZ550S2E-TTL
  • WIZ550S2E-TTL dimensions
  • WIZ550S2E-TTL pin functionality

WIZ550S2E-TTL

Excl. Tax: €21.30 Incl. Tax: €25.35
  • Buy 100 for €18.50 (€22.02 incl. tax) each and save 14%
  • Buy 1000 for €15.80 (€18.80 incl. tax) each and save 26%

Quick Overview

The WIZ550S2E-TTL module includes Serial-to-Ethernet functionality. Hardwired TCP/IP W5500 included, TTL logic level input/output pins

Details

Product Description

The WIZ550S2E-TTL is a gateway module that provides a RS-232 to TCP/IP converter This module enables remote management of a device through the network based on Ethernet and TCP/IP by connecting to an existing equipment with RS-232 serial interface. It includes the W5500 chip, which is providing hardwired TCP/IP Ethernet functionality. Furthermore, a Cortex M0 microcontroller is also included on this module. The module has TTL level logic inputs and outputs and can be combined with Interface Boards (WIZ550S2E-232-IBWIZ550S2E-485-IB) to provide RS232 or RS244/485 functionality.

Features

  • Serial to Ethernet module based on W5500 & Cortex ARM M0
  • Module with pin headers with a pitch of 2.54mm (bread-board compatible)
  • configurable via AT commands & configuration tool
  • supports data communication using AT command : able to send data without re-configuring and re-boot of the module when changing the destination IP
  • interface boards for RS-232 and RS422/485 available
  • Dimension (mm) : 55(L) x 30 (W) x 23.49 (H)



Related Links

WIZ550S2E-TTL Overview

A simple IoT example – CO2 Sensor with WIZ550S2E

More references for WIZ550S2E-TTL in the WIZnetMuseumLogo WIZnetMuseum

Additional Information

Dimension 55 x 30 x 25 mm
Ethernet I/F N/A
Operating Temperature -40° to +85° Celsius
Operating Voltage N/A
Functions N/A
Auto Negotiation Yes
Package N/A
pin count N/A
auto MDIX N/A
Wake on Lan N/A
Power Down Mode N/A
typ. Power Consumption 140 mA
MCU core LPC11E36FHN33
MCU I/F N/A
PHY chip internal
Related Chip/Module N/A
Connector Type N/A
Serial I/F N/A
serial connector count N/A
Ethernet connector N/A
pin pitch N/A
voltage regulator (LDO) N/A
MAC address inside N/A
PoE possible N/A
Ethernet Speed N/A
UART (max speed) N/A
Manufacturer No
